VB-2560 60deg V-Bit
VB-2560 60deg V-Bit
$24.00 Excl. VAT
SKU: VB-2560
- Free shipping on all orders
- No hassle returns, within 7 days
-
Guaranteed secure & safe checkout.
Description
Heat of Summer Sale - 20% Off
We’re turning up the savings on select Cyclone Bits products for a limited time.
60° V-Bit
Tungsten Carbide • Nano Blue Coated
Overview
Built for engraving, lettering, chamfers, and decorative detail work. The 60° geometry offers a strong balance of edge durability and fine detail, while the Nano Blue coating improves heat resistance and tool life during high-speed CNC cutting.
Best For
- V-carved text and graphics
- Chamfering edges
- Decorative detailing
- Sign making and inlays
Why Choose It
- Stronger edge than sharper V-bits
- Cleaner medium-detail results than wider angles
- Helps reduce tip wear on long engraving jobs
Starting Parameters
Conservative starting values. Adjust for material, machine rigidity, and toolpath strategy.
- Spindle: 16,000–20,000 RPM
- Feed: 80–160 IPM
- Plunge: 30–60 IPM
- Depth Strategy: Use shallow passes for consistent line width and finish
Compatible Materials
- Hardwood and softwood
- Plywood and MDF
- Plastics and acrylic
- Foam and composites
Specifications
- Tool Type: V-Bit
- Included Angle: 60°
- Flutes: 3
- Overall Length: 2.36"
- Shank Diameter: 1/4"
- Material: Tungsten Carbide
- Coating: Nano Blue
Notes
- Line width is controlled by depth of cut
- Best results come from rigid machines and accurate Z-zeroing
- Zero Z carefully to avoid over-cutting
Specifications
- Package: 1
- Part#: Part#
- Coating: Coating
